Overview

Contactless card provides great security and contains approximately 100 times the data storage of a traditional proximity card. The contactless card uses a technology to pass data between the card and the reader without any physical contact being made. There are no contacts to wear out, no chance of an electric shock coming through the contacts and destroying the integrated circuit.
MIFARE® is a 13.56 MHz contactless technology family of microprocessors developed by Philips. MIFARE is the most common contactless chipset on the market and is used in most applications such as access control, cashless vending, mass transit, and payment systems.

For further information about Mifare Contactless Chip, please visit NXP Semiconductors (found be Philips).

   Card Model:

Card Type

Dimension

  Available Technology :
  •Ultralight
  •1K
  •4K
  •Desfire 4K
  Application:
  • Access Control
  • Building ID
  • Customer Loyalty Programs
  • Transportation Storage Card
  • Logistics,Distribution Management
  • Time attendance,Identification
ISO Card

85.6(L)mm x 54(W)mm x 0.82(T)mm


Clamshell Card
(Thick Card)
85.6(L)mm x 54(W)mm x 1.9(T)mm



Specification


Mifare Ultralight / 1K / 4K / Desfire

 System characteristics
MIFARE
ULTRALIGHT MF0 1C U1
MIFARE
1 K
MF IC S50
MIFARE
4K
MF IC S70
MIFARE
DEFIRE 4K
MF3 IC D40
 Total memory capacity
512 Bits EEPROM
1024 bytes x 8 Bit (1kByte) EEPROM
4096 Bytes x 8 Bit
(4kByte) EEPROM
 Usable memory capacity
384 Bit
752 Bytes
3440 Bytes
3936 Bytes
 Frequency
13.56 MHz
13.56 MHz
13.56 MHz
 Read transfer speed
106 kBit/s
106 kBit/s
106-424 kBit/s
 Write transfer speed
106 kBit/s
106 kBit/s
106-424 kBit/s
 Transaction time
< 35 ms
< 100 ms
< 80 ms
 Read distance
up to 100 mm
 Write distance
up to 100 mm
 Data integrity and multi-card handling
Anti-collision

 Chip Service Life Write  Cycles Data Retention

100,000 times
5 years



100,000 times
10 years




*Anti-Collision -- the ability to handle more than one card in the field at one time

 Security Features MIFARE ULTRALIGHT
MF0 1C U1
MIFARE 1 K
MF IC S50
MIFARE 4K
MF IC S70
MIFARE DEFIRE 4K
MF3 IC D40
 Unique ID
7 bytes
4 bytes
7 bytes
 Key   32Bit prog-OPT-zone
2keys
               4keys
 DES
No
No
               Yes
 3DES
No
No
 MAC
No
Yes
               Yes
 Checksumcalculation
Yes
 Official Specificaiton
